| Specifications |
| Model No. |
MPJ55LHX18 |
| Panel Size |
55” IPS DID LCD Screen with LED backlight(with narrow bezel 1.8mm) |
| Aspect Ratio |
16:9 |
| Max Resolution Support |
1920×1080(H×V) |
| Color |
8Bit,16.7M |
| Brightness (nits) |
700 cd/㎡ |
| Contrast |
1200:1 |
| Visual Angle (H/V) |
178°(H) / 178°(V) |
| Response Time (G-to-G) |
6ms |
| Life(hrs) |
>60,000(hrs) |
| Orientation(Landscape/Portrait) |
Yes/Yes |
| Antireflexive surface |
Haze 44% |
| Operation mode |
24/7 |
| Input and output |
| DVI |
1 |
| HDMI |
1 |
| DP |
1 |
| D-15 RGB Input(VGA) |
1 |
| YUV/YPbPR |
1(3xBNC) |
| S-(YC) |
1(2xBNC) |
| HDMI loop |
1 |
| Control signal input and loop out |
RS232(RJ45-8), LAN Interface |
| Composite Video Input/(AV) |
3(3xBNC) |
| Composite Video Output |
2(2xBNC) |
| AUDIO INPUT |
1 |
| Split Screen |
Support Picture in Picture(PIP/POP/PAP) |
| Power |
| Power Supply |
AC100V~240V |
| Maximum Power Consumption |
230W |
| Standby Power Consumption |
<=3W |
| Dimension |
1215.3×684.3mmx129mm |
| Working Temperature |
0°C ~ 50°C |
| Working Humidity |
10%-90% RH |
