| Model |
BS910 PC Version |
BS910 Android Version |
| Display |
Panel Brand: Samsung & LG, 100% new A+ Grade panel |
| Panel Size: 43″ (option 32″–75″) |
| Active Area: 930 mm (H) × 523 mm (V) |
| Aspect Ratio: 16:9 |
| Resolution: 1080 × 1920 (Full HD) |
| Viewing Angle: 89/89/89/89 (CR≥10) |
| Number of Colors: 16.7 million |
| Backlight: LED |
| Brightness: 450 cd/m² |
| Contrast Ratio: 1300:1 |
| Operating System |
Motherboard: i5-3317U (optional) |
CPU: RK3288 (optional) |
| RAM: 4 GB |
RAM: 2 GB |
| Storage: 128 GB SSD (optional) |
Storage: 8 GB eMMC (optional) |
| OS: Windows 7 / 8 / 8.1 / 10 |
OS: Android 4.2 / 4.4 / 5.1 / 6.0 / 7.1 |
| RJ45, 4G (option), WiFi (option) |
RJ45, 4G (option), WiFi (option) |
| Touch System |
Infrared touch screen (touch foil, capacitive) |
Infrared touch screen (touch foil, capacitive) |
| Control: finger / touch pen |
Control: finger / touch pen |
| 10 touch points (option 20 / 40) |
10 touch points (option 20 / 40) |
| Durability: > 50 million touches |
Durability: > 50 million touches |
| Power |
140 W |
120 W |
| AC 100–240 V, 50/60 Hz |
AC 100–240 V, 50/60 Hz |
| Long-term stable operation |
Long-term stable operation |
| Technical Specifications |
VGA / HDMI / USB |
HDMI / USB / SD |
| Operating temperature: 0°C – 50°C |
Operating temperature: 0°C – 50°C |
| Material: Aluminum alloy + tempered glass |
Material: Aluminum alloy + tempered glass |
| Surface: Painted, matte aluminum |
Surface: Painted, matte aluminum |
| Dimensions: Undefined |
Dimensions: Undefined |
| Weight: Undefined |
Weight: Undefined |
| Enclosure |
Galvanized steel sheet, thickness 1.0–1.5 mm |
| Colors: Black / White / Silver / Custom |
| Packaging: Carton with inner foam + wooden crate |
| Additional Options |
Anti-glare |
| 3G/4G support |
