| Components |
Model |
Details |
| Media Player |
Android-RK3288 |
GPU |
ARM Mali-T764 GPU |
| CPU |
Quad core Cortex-A17, 2.0GHZ |
| DDR |
2G |
| ROM NAND FLASH |
8G(Exteral ROM Support up to 32G bytes sd card) |
| WIFI |
High quality WiFi module included (802.11 B/G/N) |
| Network Interface Card |
10/100/1000 Mbits/sec Ethernet LAN connectivity |
| Content Management Software included |
setup your own server or use Marvel cloud service(Marvel Cloud:http://inf.marveltechgroup.com) |
| OS |
Android 5.1.1 |
| Panel |
LG Glass |
Brightness |
2500nits&500nits |
| Angle |
178°/178° |
| Contrast |
1300:1 |
| Backlight tube life |
more than 50,000 hours |
| Operating temperature |
0-50°C |
| Response Time |
8ms |
| Max. resolution |
1920*1080 |
| Power |
Input Voltage |
AC100~240V 50 /60 HZ |
| Power Consumption |
140-150W |
| Standby power consumption |
<5W |
| Enviroment |
Work Temperature |
0-50℃ |
| Storage Temperature |
-20-60℃ |
| Work Humidity |
10%-90% |
| Storage Humidity |
5%-95% |
| OSD Language |
English/Chinese Multi-Language Supported |
| Speakers |
OP‐100 |
Dual channel amplified speakers for Stereo ,8Ω 5W |
| Cabinet |
Marvel |
Dimention |
Decided when finish production |
| Color |
Optional by customer |
| 1.5mm mild steel sheet |
